fiber optic splice closure

fiber optic splice closure,splice closure,fiber optic closure Structural features: a. corrosion resistance, high mechanical. b. connector box silicon sealed, simple operation, easy maintenance. c.According to the requirement,Make splice closure to connect the earth with special the tools for poles and towers. Technical parameters: a. fiber radius of curvature ≥ 43mm. b. the length of storge fiber optical ≥ 1500mm. c. additional consumption of storge optic cable≤ 0.01dB. d. the maximum capacity of optical fiber ≤144-core e. temperature range-40centigrade +80 centigrade. f. flattening performance :2000N/100mm. g. Weight 6.7kg. h. size 480mm (H) × 200mm (φ). Ordering Information: a. the number of OPGW cable cores. b. the quantity of enter and out. c. for pole and tower.If ploe use,note the diamater.
